| Product Center > Connector adapter > FFC/FPC Connector > Spacing 1.0mm

Scan code to browse

3D fileXB-FPC-CF-5021D0RF-10-NH Specifications XB-FPC-CF-30
DrawingsXB-FPC-CF-5021D0RF-10-NH

▍Xibang material number：XB-FPC-CF-5021D0RF-10-NH

Product Name: FPC Connector/FFC Connector Rated Current: 0.3A/0.5A DC/AC Rated Voltage: 30V 50V DC/AC Withstand Voltage: 250V AC

Contact resistance: 30M Ω Insulation resistance: 100M Ω Welding method: Reflow soldering/Wave soldering Packaging method: Ribbon/Tube assembly

Working temperature: -40 ° C ± 85 ° C Terminal material: Phosphorus copper Plastic material: LCP UL 94V-0 Product compliance: ROHS

3D file and drawings

3D fileXB-FPC-CF-5021D0RF-10-NH Specifications XB-FPC-CF-30

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-FPC-CF-5021D0RF-10-NH 3D Drawings		FPC connector/side plug FFC flexible connector/FF connector/FPC connector spacing: 1.0mm/FPC wire to board connector SMT/FPC socket/FPC interface/flexible ribbon cable connector 21PIN		Normal	4-7 days	0.170	5000 pieces/disc	15000	10000	No competitors	Consult

Product material	1. FPC connector/FFC connector	material quality
	2. The main body	LCP (natural color) UL 94V-0
	3. Lock buckle	LCP (black) UL 94V-0
	4. Terminal	phosphor copper
	5. Positioning film	yellow metal

Product type features	rated voltage	30V/50V AC/DC
	rated current	0.3A/0.5A AC/DC
	operating temperature range	-40°C±85°C
	Storage temperature range	-40°C±85°C
	contact resistance	30mΩ
	insulation resistance	100mΩ
	withstand voltage	250V AC

machine accessory	PCB installation fixed type:	soldering-block
	Connector installation type:	Board installation

Welding experiment	The solder part was immersed in a tin furnace of 245℃± 5℃ for 3 seconds	The welding end shall be easily moistened by molten material and the tin area shall occupy more than 90% of the immersion area

Heat resistance of welding tin	Pre-heating: 150~180°C	Posttest connection impedance values in the
	Welding: 250 ± 5℃	Below 50m Ω and no abnormal appearance FPC retention strength above PIN number X0.3N
	Peak temperature: 250 ± 5°C
	230℃ and above 30 ± for 5 seconds
Recommended welding conditions (temperature / welding time)	Pre-heating: 150~180°C
	Welding: 250 ± 5℃
	Peak temperature: 250 ± 5°C
	230℃ and above 30 ± for 5 seconds
This temperature graph is only for reference, and can be changed according to the type and quantity of solder
