XB-TM-W-09TP| Product ID | Product Image | Product Description | Product Code | Production status | Shipping Cycle | Gross item weight | MPQ | MOQ | Production in transit | Competitive purchases | Operation |
XB-TM-W-09TP  3D
 Drawings |
 |
MINI detection switch/detection microswitch/SMT limit switch/reset switch SMT/travel switch SMD/reset detection switch surface mounting | Normal | 4-7 days | 0.000 | 500 | 2000 | 10000 | No competitive products |
| Product material | 1. Check the switch | nylon |
| 2. The lid | nylon | |
| 3. The foundation | nylon | |
| 4. Contact with the spring | Brass silver plated | |
| 5. Terminal | Brass silver plated | |
| Use the temperature range | -40℃ to +85℃ | |
| Maximum rating (resistance load) | 0.1A 30V DC | |
| Minimum rating (resistance load) | 50μA 3V DC | |
| Electric performance | withstand voltage | 100V AC |
| insulation resistance | 30MΩ min.100V DC | |
| Contact resistance (initial / post-life) | 1Ω max./2Ω max. | |
| lasting quality | No load life | 50,000 |
| Load life (maximum rated load) | 50,000 | |
| Environmental resistance | Cold resistance | -40℃ 500h |
| resistance to effect of heat | 85℃ 500h | |
| Moisture resistance | 60℃, 90 to 95%RH 500h | |
| welding condition | ||
| When automatically immersed in welding | preheat temperature | 100℃max. |
| Preheat temperature time | 60 Seconds | |
| welding temperature | 255±5℃ | |
| Welding impregnation time | 5±1s | |
| Hand welding | welding temperature | 350±5℃ |
| weld period | 5 Seconds | |
