XB-CSD-09A001Z-R0-LF
  • XB-CSD-09A001Z-R0-LF
  • XB-CSD-09A001Z-R0-LF
  • XB-CSD-09A001Z-R0-LF
Scan code to browse
  • XB-CSD-09A001Z-R0-LF
  • XB-CSD-09A001Z-R0-LF
  • XB-CSD-09A001Z-R0-LF

3D file Specifications CSD
DrawingsXB-CSD-09A001Z-R0-LF

Xibang material number:XB-CSD-09A001Z-R0-LF

Product type: Micro Sd socket connector Rated current: 0.5A Rated voltage: 5V DC Withstand voltage: 500V AC

Insertion and extraction force: 0.3N-0.9N Contact resistance: 30m Ω max Insulation resistance: 1000 M Ω min Service life: 5000 times

Plastic Material: LCP/PA Spring Material: SUS304 Shell: SUS Stainless Steel Terminal Electroplating: Silver/Gold Plating

Working temperature: -25 ℃~+85 ℃ Installation method: Surface mount Packaging method: 1000PCS/Reel Product compliance: ROHS



3D file and drawings

3D file Specifications CSD

  • Part number information
  • Technical Features
  • Technical Drawings
  • Product Specifications
Product ID Product Image Product Description Product Code Production status Shipping Cycle Gross item weight MPQ MOQ Production in transit Competitive purchases Operation
XB-CSD-09A001Z-R0-LF
     Drawings
XB-CSD-09A001Z-R0-LF
XB-CSD-09A001Z-R0-LF
SD memory card connector/SD card slot/SD card socket/SD card socket/SD interface/Secure Digital card slot/memory card connector Micro SD card holder connector Normal 1-2 weeks 0.5g 1000 PCS/disk 30000 PCS/box 10000 No competitors
product material 1.Micro  SD connector Material
2.Plastic LCP/PA /UL94V-0
3. High temperature resistant materials LCP/PA /UL94V-0
4.Terminal copper alloy
5. Shell SUS/Copper Alloy
Electrical properties Rated current 0.5A DC
Rated voltage 5VDC
Insertion and extraction force 0.3N-0.9N
Withstand voltage 500VAC
Insulation resistance 1000MΩ
Contact resistance (initial/after life) 30MΩ
Durability No load life 5000 times
Load life (maximum rated load) 5000 times
Environmental resistance  Cold resistance -40±3℃ for 48h
 Heat resistance 85±2℃ for 48h
 Moisture resistance 40±2℃, 90 to 95%RH for 48h
Weldability Immerse the soldering terminals into velvet tin at 235°C for 3±0.5s with a minimum immersion depth of 2mm. More than 95% of the surface of the tin-immersed part must be well dipped in tin
Resistant to reflow heat Preheating: 150°C~200°C 60~120s Heating 217°C 60s Heating peak 260°CMAX: 5s~10s The appearance should be free of damage, the terminals should not be loose, and the plastic should not be deformed.
