3D fileXB-DC-011D-10A-2.5 Specifications XB-DC-011D-10A-2.5-
DrawingsXB-DC-011D-10A-2.5

▍Xibang material number：XB-DC-011D-10A-2.5

Product type: DC socket Rated current: 6A 10A Rated voltage: 12V 30V DC

Contact resistance: 30m Ω max Voltage resistance: 500 V AC MIN Insulation resistance: 100M Ω min

Life test: 5000 fog tests: 24 hours Installation method: Horizontal plug-in

Insertion and extraction force: 2-30 N Extraction force: 2-30 N Product certification: ROHS

3D file and drawings

3D fileXB-DC-011D-10A-2.5 Specifications XB-DC-011D-10A-2.5-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-DC-011D-10A-2.5 3D Drawings		High current DC socket sinking plate 7A High power DC mother base 10A		Normal production	5-10 days	0.3	1000	5000			Consult

产品材质	Terminal:	SUS301 N/A
	SHELL:	C2680R-EH Ni 50U
	CENTER PIN(+) :	C3601 Gold flash ocer ni 50u
	SHUNT TERMINAL :	C2680E-EH Gold flash on contact area：100u,sn on solder tail all over ni 50u min
	TIP SPRING(-) :	C5210R-EH Gold flash on contact area：100u,sn on solder tail all over ni 50u min
	HOUSING:	LCP UL 94V-0(HF) Black

环境条件	Temperature range:	-20 °C/+70 °C

	Mating cycles:	5000
	Insertion force:	≤ 30 N *1
	Withdrawal force:	3–30 N *2

电气数据	Contact resistance:	≤ 30 mΩ
	Rated current:	10 A
	Rated voltage:	20 V DC
	Rated impulse voltage:	500 V/60 s
