XB-PM2142-ATX30U-F| Product ID | Product Image | Product Description | Product Code | Production status | Shipping Cycle | Gross item weight | MPQ | MOQ | Production in transit | Competitive purchases | Operation |
XB-PM2142-ATX30U-F-X  3D
 Drawings |
 |
11x5.8x12.5mm solder wire 2PIN connector high current/2P socket high power/new energy TX30 connector/aircraft model 2P battery holder/high current 2-core socket | XT connector | Normal | 5 days/7 days | 0.25g | 1000 | 3000 | 100000 | Nothing |
| product material | 1.XT30 connector | Material | ||
| 2.Hardware | gold plated brass | |||
| 3. Plastic shell | PA66 | |||
| 4.Surface treatment | Gold plating (1μ~3μ) | |||
| Electrical properties | Rated current | 15A | ||
| Rated voltage | 500V DC | |||
| Insertion and extraction force | 12N~35N | |||
| Withstand voltage | 500V DC | |||
| Insulation resistance | 2000MΩ | |||
| Protection level | IP40 | |||
| Creepage distance | 3.46mm | |||
| Contact resistance (initial/after life) | 1.20MΩ | |||
| Durability | No load life | 5000 times | ||
| Load life (maximum rated load) | 5000 times | |||
| Environmental performance | Operating temperature | -20°C±120°C | ||
| Wiring recommendations: | ||||
| AWG | Temperature rise 60°C | Temperature rise 85°C | ||
| 16# | 20A | 25A | ||
| 18# | 15A | 20A | ||
| 20# | 10A | 15A | ||
