| Product Center > Socket > USB socket > USB 3.2 A-type connector

Scan code to browse

3D fileXB-U234-051N-3GRA035-5 Specifications USB3.0通用
DrawingsXB-U234-051N-3GRA035-5

▍Xibang material number：XB-U234-051N-3GRA035-5

产品证书

UL/CUL:E523734

3D file and drawings

3D fileXB-U234-051N-3GRA035-5 Specifications USB3.0通用

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-U234-051N-3GRA035-5 3D Drawings		XB-U234-051N-3GRA035-5 USB 3.0 female horizontal plug-in/USB connector 3.0/USB socket 9PIN/USB female socket 3.0/USB socket 3.0/USB socket 9PIN									Consult

产品材质	Housing Material:	Thermoplastic PA9T, UL94V-0, green
	Contact Terminal:	Brass 1" Gold
	Metallic Shell:	Brass Nickel

产品类型特性	连接器种类:	母端
	方向:	直角
	连接器系统:	缆到板
	Sealable:	是
	连接器和端子端接到:	印刷电路板
	端口数量:	1

端接特性	端子端接类型:	表面贴装
	PCB端接方法:	表面贴装

接触件特性	端子额定电流（最大值）(A):	4A

机械附件	安装位置:	中间安装
	PCB 安装固定类型:	SMT + 通孔
	连接器安装类型:	板安装

使用环境	焊接温度（最大值）:	260°C
	插接周期（最大值）:	5000
	工组温度范围:	-40°C ~ +85°C

操作/应用	能够拾放:	否
	电路应用:	电源和信号

包装特性	封装方法:	卷
