3D fileXB-X35-CP-0502S0000 Specifications CP
DrawingsXB-X35-CP-0502S0000

▍Xibang material number：XB-X35-CP-0502S0000

Nom du produit: connecteur fil à carte courant nominal: 1a DC / AC Tension nominale: 1400v DC / AC résistance à la tension: 3800v AC

Résistance de contact: 30mΩ résistance d'isolation: 1000mΩ méthode de soudage: fil de soudage / plaque de soudage température de fonctionnement: - 25 ℃ ~ + 85 ℃

Matériau du terminal: cuivre phosphaté plaqué argent / or matériel en plastique: LCP durée de vie: 5000 fois conformité du produit: ROHS

3D file and drawings

3D fileXB-X35-CP-0502S0000 Specifications CP

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-X35-CP-0502S0000 3D Drawings		High voltage line board locking crimping shell/CP connector shell/CP connector shell/wire to board connector/CP crimping shell/wire to board crimping adhesive shell connector		Normal	1-2 weeks	0.3g	1000 PCS/disc	5000 PCS	10000	Nothing	Consult

Product material	1. Line to board connector	material quality
	2. The shell	UL 94V-2/UL94V-0
	3. Terminal	Phosphorus copper is silver plating / phosphorus copper gold plating
	3. Rubber shell	LCP
	4. The PIN needle No	Phosphorus copper is silver plating / phosphorus copper gold plating

Product type features	rated current	1A AC/DC
	rated voltage	1400V AC/DC
	operating temperature range	-25°C±85°C
	contact resistance	30mΩ
	insulation resistance	1000 mΩ
	withstand voltage	3800V AC

Environmental resistance	Cold resistance	-25±2℃ 96/h
	resistance to effect of heat	85 ± 2 ℃ 96/h
	Moisture resistance	40 ± 2℃ relative humidity 90~95% 96 / h

machine accessory	way to install	Welding wire / welding plate
	Connector installation type:	Board installation

Welding experiment	Dip the terminal foot in the flux for 5 seconds, then immerse the terminal foot in a 255 ± 5℃ tin furnace for 3 ± 0.5 seconds	The tin attached area shall exceed 95% of the immersion surface area

Heat resistance of welding tin	The terminals shall be tested for tin resistance under the following conditions, and test the contact impedance after solder heat resistance
	Based on: EIA-364-56A	No cracks, scratches, and breaks
	Weldability temperature: 250 °± 5C
	Time: 5s + / -1s
Reflow welding and wave crest welding experiments	wave-soldering	The recommended solder temperature is 260℃ (500°F) for a maximum of 5 seconds
	Hand welding	The 30W flipping iron is used to control the temperature at 350℃, and the welding time is about 5 seconds
	Back furnace welding	The maximum temperature of SMT backwelding furnace is 260℃ and the temperature is 260℃, the maximum time shall not exceed 10 seconds
