▍Xibang material number：XB-X25-CI22-16P1HK0

Product Name: Line to Board Connector Rated Current: 3A DC/AC Rated Voltage: 250V DC/AC Withstand Voltage: 1000V AC

Contact resistance: 30M Ω Insulation resistance: 100M Ω Welding method: Welding wire/welding plate Working temperature: -40 ℃~+85 ℃

Terminal material: phosphor copper silver plated/gold plastic material: LCP Service life: 5000 times Product compliance: ROHS

3D file and drawings

3D fileXB-X25-CI22-16P1HK0 Specifications XB

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-X25-CI22-16P1HK0 3D Drawings		Wire to board crimping connector/wire end connector DIP/terminal connector spacing: 2.50mm/wire to board connector/crimping connector/piercing connector 16PIN		Normal	1-2 weeks	0.3g	1000 PCS/disc	5000 PCS	10000	Yes	Consult

Product material	1. Line to board connector	material quality
	2. The shell	UL 94V-2/UL94V-0
	3. Terminal	Phosphorus copper is silver plating / phosphorus copper gold plating
	3. Rubber shell	LCP
	4. The PIN needle No	Phosphorus copper is silver plating / phosphorus copper gold plating

Product type features	rated current	3A AC/DC
	rated voltage	250V AC/DC
	operating temperature range	-40°C±85°C
	contact resistance	30mΩ
	insulation resistance	100 mΩ
	withstand voltage	1000V AC

Environmental resistance	Cold resistance	-25±2℃ 96/h
	resistance to effect of heat	85 ± 2 ℃ 96/h
	Moisture resistance	40 ± 2℃ relative humidity 90~95% 96 / h

machine accessory	way to install	Welding wire / welding plate
	Connector installation type:	Board installation

Welding experiment	Dip the terminal foot in the flux for 5 seconds, then immerse the terminal foot in a 255 ± 5℃ tin furnace for 3 ± 0.5 seconds	The tin attached area shall exceed 95% of the immersion surface area

Heat resistance of welding tin	The terminals shall be tested for tin resistance under the following conditions, and test the contact impedance after solder heat resistance
	Based on: EIA-364-56A	No cracks, scratches, and breaks
	Weldability temperature: 250 °± 5C
	Time: 5s + / -1s
Reflow welding and wave crest welding experiments	wave-soldering	The recommended solder temperature is 260℃ (500°F) for a maximum of 5 seconds
	Hand welding	The 30W flipping iron is used to control the temperature at 350℃, and the welding time is about 5 seconds
	Back furnace welding	The maximum temperature of SMT backwelding furnace is 260℃ and the temperature is 260℃, the maximum time shall not exceed 10 seconds
