Product material
|
1. BTB Board to Board Connector
|
material quality
|
|
2. The shell
|
PA9T UL94V-0
|
|
3. Terminal
|
Brass Gold plated
|
|
|
Product type features
|
rated current
|
0.3A/0.5A AC
|
|
rated voltage
|
30V/60V AC
|
|
operating temperature range
|
-55℃～+125℃
|
|
Storage temperature range
|
-55℃～+125℃
|
|
contact resistance
|
30mΩ≥90mΩ
|
|
insulation resistance
|
100 mΩ
|
|
withstand voltage
|
150V AC
|
|
|
Environmental resistance
|
Cold resistance
|
-25±2℃ 96/h
|
|
resistance to effect of heat
|
85 ± 2 ℃ 96/h
|
|
Moisture resistance
|
40 ± 2℃ relative humidity 90~95% 96 / h
|
|
|
machine accessory
|
way to install
|
soldering-block
|
|
Connector installation type:
|
Board installation
|
|
|
Packaging characteristics
|
Packaging method (patch SMD):
|
braid
|
|
|
Welding experiment
|
Dip the terminal foot in the flux for 5 seconds, then immerse the terminal foot in a 255 ± 5℃ tin furnace for 3 ± 0.5 seconds
|
The tin attached area shall exceed 95% of the immersion surface area
|
|
|
Heat resistance of welding tin
|
The terminals shall be tested for tin resistance under the following conditions, and test the contact impedance after solder heat resistance
|
|
Electric soldering iron: 2 times
|
No cracks, scratches, and breaks
|
|
temperature:≤350℃
|
|
Time: 5s + / -1s
|
|
Reflow welding and wave crest welding experiments
|
wave-soldering
|
The recommended solder temperature is 260℃ (500°F) for a maximum of 5 seconds
|
|
Hand welding
|
The 30W flipping iron is used to control the temperature at 350℃, and the welding time is about 5 seconds
|
|
Back furnace welding
|
The maximum temperature of SMT backwelding furnace is 260℃ and the temperature is 260℃, the maximum time shall not exceed 10 seconds
|
|
0769-82056828
XB-0403FSV34-XXXXX01
