XB-MSK-005C-6P-U| Product ID | Product Image | Product Description | Product Code | Production status | Shipping Cycle | Gross item weight | MPQ | MOQ | Production in transit | Competitive purchases | Operation |
XB-MSK-005C-6P-U  3D
 Drawings |
 |
9 * 3.5 * 3.6mm small current toggle switch 6-pin/mini toggle switch SMD/sliding switch 2nd gear/mini 2nd gear switch 6-pin/dip switch/wave switch/2P2T side dip toggle switch | Normal | 7-10 days | 0.00 | 500 | 1000 | 10000 | Nothing |
| Product material | 1. Mini switch | material quality |
| 2. Slide the handle | POM | |
| 3. The shell | Brass silver plated | |
| 4. The contact point | Brass gold plated | |
| 5. Terminal | Brass silver plated | |
| Use the temperature range | -40℃ to +85℃ | |
| power rating | 0.3A 0.5A 12V 30V | |
| Electric performance | withstand voltage | 500V DC |
| insulation resistance | 100MΩ min. | |
| Contact resistance (initial / post-life) | Maximum:: 30m Ω / max.: 100m Ω | |
| lasting quality | No load life | 10000 Times |
| Load life (maximum rated load) | 10000 Times | |
| Environmental resistance | Cold resistance | -20℃ 500h |
| resistance to effect of heat | 85℃ 500h | |
| Moisture resistance | 60℃, 90 to 95%RH 500h | |
| welding condition | ||
| When immersed in welding | preheat temperature | 100℃ |
| Preheat temperature time | Maximum 60 seconds | |
| welding temperature | 260±5℃ | |
| Welding impregnation time | 3±1s | |
| Hand welding | welding temperature | 350±10℃ |
| weld period | Maximum 3 seconds | |
