3D fileXB-HR31-M84A-1P-F1C-R Specifications XB-HR31-M84A-1P-F1C-R-
DrawingsXB-HR31-M84A-1P-F1C-R

▍Xibang material number：XB-HR31-M84A-1P-F1C-R

Product type: Rotary switch Rated current: 8A 12A Rated voltage: 125V 250V AC Contact resistance: 30mΩmax

Withstand voltage: 1500V AC Insulation resistance: 100 MΩ min Life test: 5000 times Working temperature: -40℃±125℃

Plastic material: PA66/POM Terminal material: Silver-plated brass Operating force: 220±30gf Product compliance: ROHS

3D file and drawings

3D fileXB-HR31-M84A-1P-F1C-R Specifications XB-HR31-M84A-1P-F1C-R-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-HR31-M84A-1P-F1C-R 3D Drawings		36.6 * 38 * 20.2mm fluctuation rotary switch/8-speed band rotary switch/8-position power supply rotary switch/toggle rotary switch/high current band switch		Normal	7-15 days	0.3g	1000	5000	1000	Nothing	Consult

Product type features	1. Rotation switch	material quality
	2. Button	POM
	3. The shell	PA66
	4. Terminal	Brass silver plated

1. Operating temperature range:		-40℃±125℃
2. Rated value:		8A 12A 125V 250V AC
3. Insulation resistance:		100MΩ
4. Voltage resistance		1500V AC
5. Contact resistance:		30MΩ
6. Life:		5000 Times
7. Operation force		1000±300gf

Environmental resistance	Cold resistance	-30±2℃ 96/h
	resistance to effect of heat	85±2℃ 96/h
	Moisture resistance	85 ± 2℃ relative humidity at 85% 500 / h
