▍Xibang material number：XB-TM-2122L-X

Product type: dial Switch Rated current: 0.1A 0.5A Rated voltage: 12V 30VDC Withstand voltage: 250V DC

Contact resistance: 30m Ω Insulation resistance: 100M Ω Life test: 50000 times Working temperature -40 ℃± 85 ℃

Plastic material: PA66/POM Terminal material: Brass silver plated Working temperature: -40 ℃ ± 85 ℃ Product meets: ROHS

3D file and drawings

3D fileXB-TM-2122L Specifications 规格书-1

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-TM-2122L-X 3D Drawings		Shake head switch three way 10.20 * 13 * 2.6mm SMD dial switch/Shake head switch left and right reset middle button/Reset switch left and right reset middle button/Three way toggle switch left and right reset middle button/Swing switch 3 way/Dial switch		Normal	4~7 days	0.5	1000	50000	10000	Nothing	Consult

Product material	1. Dial switch	PA46/PA66
	2. The lid	SUS
	3. Spring	SUS
	4. The foundation	PA46/PA66
	5. Touch	Brass silver plated
	6. Terminal	Brass silver plated

	Use the temperature range	-40℃±85℃
	Maximum rating (resistance load)	0.1A 6V
	Minimum rating (resistance load)	0.5A 12V

Electric performance	withstand voltage	250V AC
	insulation resistance	30MΩ min.250V DC

lasting quality	No load life	50,000 (0.1A6V DC)
	load life	50,000

Environmental resistance	Cold resistance	-40±2℃ for 96h
	resistance to effect of heat	85 ±2℃ for 96h
	Moisture resistance	40±2℃, 90 to 95%RH for 96h
welding condition
Reflux welding
1. Heating method	Upper and lower heating mode for far-infrared heating
2. Temperature measurement method is used with	The CA (K) or CC (T) measurement position of φ 0.1 φ 0.2 is fixed at the welding joint (copper foil surface)
3. Temperature distribution

(1) The above conditions are the temperature of the surface of the zero part of the printed circuit board. According to the circuit board material, size, thickness, etc., the temperature of the circuit board and the switch surface temperature will be very different, about the switch surface temperature, please also use in the above conditions.
(2) According to the type of veneer welding groove, different conditions and different results, please fully confirm in advance before use.

Hand welding	welding temperature	350±5℃
	weld period	Maximum 3 seconds
	Welding times	1
