3D fileXB-SEF-0X05 Specifications LED
DrawingsXB-SEF-0X05

▍Xibang material number：XB-SEF-0X05-X

Product Name: LED Touch Switch Rated Current: 20mA Rated Voltage: 6V 12V DC Service life: 1000 hours Waterproof rating: IP50 Contact resistance: 30m Ω Insulation resistance: 100m Ω Operating temperature: -40 ℃~+85 ℃ Product certification: ROHS

3D file and drawings

3D fileXB-SEF-0X05 Specifications LED

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-SEF-0X05-X 3D Drawings		5 * 6.35 * 7.11mmLED module/LED indicator light/LED module/lighting module/LED indicator light module/indicator light module 2PIN		Normal	7/10 days	0.42g	1000	30000	Normal	Yes	Consult

product name	1.LED module	Material
	2. Shell	PBT
	3. Terminals	Brass gold plated

	Operating temperature range	-40℃~85℃
	Rated current	20mA
	Rated voltage	6V 12V DC
	LED Light	Yellow, red, blue, green, white
	LED light (current/voltage)	20mA 5V

Electrical properties	Insulation resistance	100MΩ min.
	Contact resistance (initial/after life)	30mΩ max.

Durability	No-load life	1000 hours
	Load life	1000 hours
