XB-ESM-22-13Z-32-N5-NN-X-X-Xibang Electronics Co., Ltd. is a global OEM manufacturer that provides high-performance switch, socket connector components, solutions, and intelligent engines that connect the world!

| Product Center > Switch > Emergency stop switch

Scan code to browse

3D fileXB-ESM-22-13Z-32-N5-NN Specifications ESM
DrawingsXB-ESM-22-13Z-32-N5-NN

▍Xibang material number：XB-ESM-22-13Z-32-N5-NN-X-X

Product Name: Emergency Stop Switch Rated Current: 0.2A 1A 3A Rated Voltage: 250V AC

Contact resistance: 50m Ω max Insulation resistance: 100 M Ω Voltage resistance: 1500V AC

Operating force: 450 ± 150gf Service life: 50000 times Product certificate: ROHS

3D file and drawings

3D fileXB-ESM-22-13Z-32-N5-NN Specifications ESM

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-ESM-22-13Z-32-N5-NN-X-X 3D Drawings		32mm emergency stop switch/button switch/emergency stop button switch/metal button switch/high current emergency stop switch/emergency stop switch		Normal	7 days/10 days	0.5g	500	1000	100000	Yes	Consult

product material	1.Emergency stop switch	Material
	2.Button	Zinc aluminum alloy
	3.Buttons	(new) alloy
	4.Terminal	Brass silver plated
	6. Nuts	Brass silver plated
	7.Pedestal	PBT/PA66
	8. Shell	Stainless steel

Electrical properties	Operating temperature range	-30℃±70℃
	to maximum rating (resistive load)	3A 250AC
	to minimum rating (resistive load)	0.2A 250AC
	Operating force	450gf±150gf
	Service life	50,000 times
	Withstand voltage	500VAC
	Insulation resistance	100MΩ
	Contact resistance (initial/after life)	50MΩ

Durability	No load life	50,000 times
	Load life (maximum rated load)	50,000 times

Environmental resistance	Cold resistance	-40±2°C/96h
	Heat resistance	80±2°C/96h
	Moisture resistance	40±2°90 to 95% relative humidity 96/h
