3D fileXB-PL5001-5PA Specifications EC5
DrawingsXB-PL5001-5PA

▍Xibang material number：XB-PL5001-5PA

Product name: EC5 connector Rated current: 40A Rated voltage: 500V DC Rated voltage: 500V DC Load capacity: 20N~50N

Contact resistance:0.4MΩ Use temperature:-40°±120°C Insulation resistance:2000MΩ Use life:5000次 Product code:ROHS

3D file and drawings

3D fileXB-PL5001-5PA Specifications EC5

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-PL5001-5PA 3D Drawings		19.8 * 25 * 9.7mm Automotive Power EC5 Plug Male Female Seat/Aircraft Model Lithium Battery EC5 Plug/Line End High Current EC5 Male Female Seat/New Energy High Current EC5 Connector/Banana Head EC5 Male Female Seat/Power Line EC5 Male Female Terminal	EC5	Normal	5 days/7 days	0.25g	1000	3000	100000	Nothing	Consult

product material	1.EC connector	Material
	2.Hardware	gold plated brass
	3. Plastic shell	PA6
	4.Surface treatment	Gold plating (1μ~3μ)

Electrical properties	Rated current	40A
	Rated voltage	500VDC
	Insertion and extraction force	20N~50N
	Withstand voltage	500VDC
	Insulation resistance	2000MΩ
	Contact resistance (initial/after life)	0.4MΩ

Durability	No load life	5000 times
	Load life (maximum rated load)	5000 times

Environmental performance	Operating temperature	-20°C±120°C
Wiring recommendations	AWG	Temperature rise 60°C
	18#	40A
