3D fileXB-DC-011C-SMT Specifications XB-DC-011C-SMT-
DrawingsXB-DC-011C-SMT

▍Xibang material number：XB-DC-011C-SMT

方向

水平

安装方式

表面安装

中心引脚

0.65mm

离安装面高度

5mm

屏蔽

否

额定电压

30V

额定电流

0.5A

外孔

2.6mm

外形尺寸

W11.0XD5.0XH5.0mm

产品证书

UL/CUL:E523734

3D file and drawings

3D fileXB-DC-011C-SMT Specifications XB-DC-011C-SMT-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-DC-011C-SMT 3D Drawings		DC connector horizontal patch W12xD5xH5	21945	normal	1-2 weeks	0.557	1000 pieces/bag	3000	10000	No competitive products	Consult

产品材质	Center pin:	Brass tin
	Terminal 1:	Brass ni
	Terminal 2:	Brass tin
	Terminal 3:	Brass ag
	Terminal 4:	Phosphor Bronze ag
	Plastic:	PPA

环境条件	Temperature range:	-30 °C/+70 °C

	Mating cycles:	≥ 5000
	Insertion force:	≤ 30 N *1
	Withdrawal force:	2–30 N *2

电气数据	Contact resistance:	≤ 30 mΩ
	Rated current:	0.5 A
	Rated voltage:	30 V DC
	Rated impulse voltage:	500 V/60 s
