| Product Center > Connector adapter > D-SUB Connector > D-SUB connector combination
XB-25W3-SPVXXX40D00
  • XB-25W3-SPVXXX40D00
  • XB-25W3-SPVXXX40D00
  • XB-25W3-SPVXXX40D00
Scan code to browse
  • XB-25W3-SPVXXX40D00
  • XB-25W3-SPVXXX40D00
  • XB-25W3-SPVXXX40D00

3D file Specifications SUB
DrawingsXB-25W3-SPVXXX40D00

Xibang material number:XB-25W3-SPVXXX40D00

Product Name: D-SUB Connector Rated Current: 3A Rated Voltage: 250V AC Withstand Voltage: 1000V AC

Contact resistance: 10M Ω Insulation resistance: 100M Ω Welding method: wire/plate Working temperature: -55 ℃± 125 ℃

Operating force: 17Kgf Plastic material: UL 94V-0 Service life: 5000 times Product compliance: ROHS


3D file and drawings

3D file Specifications SUB

  • Part number information
  • Technical Features
  • Technical Drawings
  • Product Specifications
Product ID Product Image Product Description Product Code Production status Shipping Cycle Gross item weight MPQ MOQ Production in transit Competitive purchases Operation
XB-25W3-SPVXXX40D00
     Drawings
XB-25W3-SPVXXX40D00
XB-25W3-SPVXXX40D00
Direct D-SUB socket connector/combination D-SUB connector DIP/D-Sub plug connector/D-SUB female socket/D-SUB male socket/D-SUB socket 25PIN Normal 1-2 weeks 5.204 230 pieces/disc 690 10000 No competitors
Product Material 1. D-SUB connector Material
2. Shell UL94V-0
3. Terminals Phosphor copper silver plated/Phosphor copper gold plated
3. Plastic shell Phosphor Bronze
Product Type Features Rated current 3A
Rated voltage 250V AC
Operating temperature range -55°C±125°C
Contact resistance 30mΩ
Insulation resistance 10mΩ
Withstand voltage 1000V AC
Environmental resistance Cold resistance -25±2℃ 96/h
Heat resistance 105±2℃ 96/h
Moisture resistance 35±3℃Relative humidity 90~95% 96/h
Mechanical accessories Installation Wire/Board Welding
Connector Mounting Type: Board Installation
Solderability test Immerse the terminal pins in the flux for 5 seconds, then immerse the terminal pins in a 230±5℃ tin furnace for 5±0.5 seconds The tin attached area should exceed 95% of the immersed surface area
Solder heat resistance The terminals should be tested for tin resistance and solder heat resistance under the following conditions and then tested for contact impedance.
Based on: EIA-364-56A No cracks, scratches or breaks
Solderability temperature: 245°±5C
Time: 3s+/-0.5s
Reflow and wave soldering experiments Wave Soldering The recommended soldering temperature for DIP type is 260°C (500°F) for a maximum of 5 seconds
Hand welding Use a 30W soldering iron to control the temperature at 380°C and solder for about 3 seconds
Reflow The maximum temperature of the SMT reflow oven is 260°C. When the temperature is 260°C, the maximum time does not exceed 10 seconds.
