▍Xibang material number：XB-PL3505-D3.5

Product name: Banana plug connector Rated current: 30A Rated voltage: 500V DC Withstand voltage: 500V DC Insertion and extraction force: 7N~15N

Contact resistance: 0.55MΩ Operating temperature: -40°C±120°C Insulation resistance: 2000MΩ Service life: 5000 times Product compliance: ROHS

3D file and drawings

3D fileXB-PL3505-D3.5 Specifications XB-PL3505-D3.5-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-PL3505-D3.5 3D Drawings		7.1 * 16.9mm banana head 3.5 single P male connector/banana joint 1PIN/banana head plug 3.5 single PIN female sheath red/banana head 1PIN/single PIN banana head high current	Banana plug connector	Normal	5 days/7 days	0.25g	1000	3000	100000	Nothing	Consult

product material	1.banana plug connector	Material
	2.Hardware	gold plated brass
	3. Plastic shell	PA6
	4.Surface treatment	Gold plating (1μ~3μ)

Electrical properties	Rated current	30A
	Rated voltage	500VDC
	Insertion and extraction force	7N~15N
	Withstand voltage	500VDC
	Insulation resistance	2000MΩ
	Contact resistance (initial/after life)	0.55MΩ

Durability	No load life	5000 times
	Load life (maximum rated load)	5000 times

Environmental performance	Operating temperature	-20°C±120°C
Wiring recommendations	AWG	Temperature rise 30K
	12#	30A
