| Product Center > Switch > Tilt Sensor Switch > Ball type

Scan code to browse

3D fileXB-SW-QD-IR09 Specifications XB-SW-QD-IR09-
DrawingsXB-SW-QD-IR09

▍Xibang material number：XB-SW-QD-IR09-X-X

Product name: ball switch Rated current: 2uA-10mA Rated voltage: 1-6V Circuit function: inclined conduction

Contact resistance:>10 M Ω Closed circuit resistance:>10 M Ω Welding temperature: 260 ℃± 10 ℃, temperature resistance: - 40 ℃ to 85 ℃

Salt spray test: 95% RH, 40 ℃ for 24 hours Service life: 100000 cycles Product certification: ROHS

3D file and drawings

3D fileXB-SW-QD-IR09 Specifications XB-SW-QD-IR09-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-SW-QD-IR09-X-X 3D Drawings		9.9 * 10.65 * 12.2mm photoelectric switch/photoelectric vibration switch/photoelectric vibration switch/4PIN photoelectric tilt switch/ball switch/ball tilt switch/tilt switch/tilt switch/vibration sensor		Normal	3~7 days	0.5	5000	5000	20000	No competitive products	Consult

product material	1. Tip sensor	Material
	2. Plastic cover	PBT
	3. Plastic seat	PBT
	4. Balls	Brass silver plated/brass gold plated
	5. Guide pin	Brass silver plated/brass gold plated
	6. Shell	PBT/PA66

	Operating temperature range	-20°C±80°C
	Working current	<12mA
	Operating Voltage	5VDC
	On-resistance	<10Ω

Electrical properties	pouring speed	>30°/s

Durability	Service life	＞50,000 hours
	Solder temperature	260°±5°C
	wave soldering	250°C±10°C
