| Product Center > Switch > Photoelectric switch > Optocoupler element > Phototransistor > 4Pin high isolation

▍Xibang material number：XB-CNY64S

Product type: Phototransistor Rated current: 60mA/200mA Rated voltage: 1.2V/80V Life test: 5000 times

Installation method: Welding insertion and extraction force: 3-30N Operating temperature: -40 ℃± 105 ℃ Product certification: ROHS

3D files and drawings

3D filesXB-CNY64S Specifications GO
一般光耦的CTR量测与计算 Ver1.0(简)
一般光耦应用于数据传送 Ver1.0(简)
3D filesXB-CNY64S Specifications GO
一般光耦的CTR量测与计算 Ver1.0(简)
一般光耦应用于数据传送 Ver1.0(简)

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-CNY64S 3D Drawings		8.56 * 7.2 * 6.01mm optocoupler/optocoupler electronic components/SMT optocoupler/optocoupler phototransistor output/inline optocoupler/optocoupler/optocoupler chip components/optocoupler 4PIN	4Pin high isolation	Normal	A week	0.36g	1000	3000	10000	Compatible Xibang	Consult
XB-CNY64S-X 3D Drawings		8.56 * 7.2 * 6.01mm optocoupler/optocoupler electronic components/SMT optocoupler/optocoupler phototransistor output/inline optocoupler/optocoupler/optocoupler chip components/optocoupler 4PIN	4Pin high isolation	Normal	A week	0.36g	1000	3000	10000	Compatible Xibang	Consult

product type	4Pin high isolation

characteristic	• High voltage BVCEO=80V (minimum value)
	• Operating temperature up to +85°C
	• High isolation voltage Viso = 8000 Vrms between input and output
	• Rated repetitive peak voltage (repetitive) VIORM = 1000 VRMS
	• Creepage current resistance complies with VDE 0303/IEC 60112 Comparative tracking index: CTI ≥ 200
	• Insulation thickness ≧3mm
	• Lead-free and RoHS compliant

Application areas	• Switch mode power supply
	• Line receiver
	• Computer peripheral interface
	• Microprocessor system interface
	• Safety protection isolation circuit (reinforced isolation) complying with safety level II to prevent electric shock

Product EIA Compliance Document

English version of PPA

SPCC English

Stainless steel English version

Nickel plating English version

English version of tin plating

Silicone English

Brass English

Phosphor copper English version

Compliant with EU RoHS (2011/65/EU) Directive

Complies with EU ELV Directive 2000/53/EC requirements
