XB-PZ-A-127-235| Product ID | Product Image | Product Description | Product Code | Production status | Shipping Cycle | Gross item weight | MPQ | MOQ | Production in transit | Competitive purchases | Operation |
XB-PZ-A-127-235  3D
 Drawings |
 |
7.62 * 3.4 * Hmm row pin connector/row pin plug 6P/row pin male 6PIN/row pin male seat/single row pin connector plug-in/double row pin connector DIP/row pin spacing 1.27mm | Normal | 7/10 days | 0.36g | 1000 | 3000 | 100000 | Yes |
| product material | 1. Female connector | Material | ||
| 2. Shell | LCP/UL94-V0 | |||
| 3. Contact | Brass/Phosphor Bronze | |||
| Operating temperature range | -40℃~105℃ | |||
| Rated current | 0.5A AC/DC | |||
| Rated voltage | 250V AC/DC | |||
| Electrical properties | Withstand voltage | 300V AC | ||
| Insulation resistance | 100MΩ min. | |||
| Contact resistance (initial/after life) | 30mΩ max. | |||
| Durability | No-load life | 5000 times | ||
| Load life | 5000 times | |||
| Environmental resistance | Heat resistance | 40°±2℃ 96/h | ||
| Moisture resistance | -20°±3° 96/h | |||
| Salt spray performance | 35°±2℃ 48/h | |||
| Infrared reflow conditions (lead-free) | ||||
| ||||
| characteristic | Lead-free components | |||
| Preheating and soaking minimum temperature | 150℃~200℃/60 to 120 seconds | |||
| Maximum temperature time | 150℃~200℃/60 to 120 seconds | |||
| Average rate of ascent | Max. 3°C/sec | |||
| Liquid temperature | 217°C | |||
| Liquefaction time | 60-150 seconds | |||
| Peak temperature of package | 260±5℃/5~15sec | |||
| At the specified grade temperature 5°C | 20~40 seconds | |||
| Average temperature drop rate | Up to 6°C/sec | |||
| Time from 25 °C to peak temperature | Up to 8 minutes | |||
